7Solutions India supports project teams with structural detailing, shop drawings, BIM, precast, rebar, modular construction documentation and engineering drawing services.
Our project work can involve a single specialist drawing package or coordinated technical support across multiple disciplines, depending on the project scope and information supplied.
Technical Support Across Different Construction Workflows
Construction projects often require more than one type of technical deliverable. A structural steel project may involve 3D modeling, member detailing, shop drawings and erection drawings, while a precast project may require component detailing, reinforcement, shop drawings and erection layouts.
This Projects page provides a high-level view of the project types and documentation workflows we support.
For actual drawing and model examples, visit the Structural Detailing, BIM & Drawing Portfolio .
- 3D structural models
- Shop drawings
- Fabrication drawings
- Erection drawings
- BIM models
- Coordination drawings
- Rebar and BBS documentation
- Precast production drawings
Types of Projects We Support
Project scopes vary, but these are the main technical workstreams represented across our service portfolio.
Structural Steel Projects
Structural steel project support can include model development, member detailing, connection references, shop drawings, fabrication information and field erection documentation.
Structural Steel Detailing →BIM & Coordination Projects
BIM work can include architectural, structural and MEP modeling, multidisciplinary coordination, clash review and model-based construction documentation.
BIM Services →Precast Concrete Projects
Precast workflows can involve panels, beams, columns, slabs, spandrels, reinforcement, production drawings, formwork modeling and erection documentation.
Precast Detailing →Reinforced Concrete Projects
Reinforcement documentation can cover slabs, columns, beams, foundations and other concrete elements requiring rebar drawings and scheduling.
Rebar Detailing →Modular & Prefabricated Projects
Modular project support can include building design, 3D visualization, shop drawings, fabrication drawings, sections, elevations and erection documentation.
Modular Building Design →Engineering & Equipment Projects
Engineering assignments can involve structural analysis, finite element modeling, equipment documentation, heat exchangers, pressure vessels and other technical drawing workflows.
Engineering Services →Steel Detailing Projects From Model to Field Documentation
Structural steel work can require coordinated information across engineering drawings, 3D models, fabrication documents and field erection packages.
The project workflow can vary from a focused shop-drawing assignment to a wider detailing package covering multiple structural and miscellaneous steel components.
- Structural 3D modeling
- Member detailing
- Steel shop drawings
- Fabrication drawings
- Erection drawings
- Connection coordination
- Stairs and miscellaneous metals
Model-Based Projects Across Architecture, Structure & MEP
BIM projects can bring multiple disciplines into a shared model-based workflow to support coordination, clash review, documentation and construction communication.
Depending on project needs, work may include Revit modeling, structural BIM, MEP BIM, architectural BIM or multidisciplinary coordination.
- Architectural BIM
- Structural BIM
- MEP BIM
- BIM coordination
- Clash detection
- Scan-to-BIM
- Model-based shop drawings
- As-Built BIM documentation
Production & Erection Documentation for Precast Systems
Precast project documentation can involve multiple component types that need to remain coordinated through production and field placement.
Shop drawings, reinforcement, component modeling and erection layouts can be developed around the supplied project design and precast requirements.
- Precast wall panels
- Precast beams
- Precast columns
- Precast slabs
- Spandrels
- Precast shop drawings
- Formwork/model coordination
- Precast erection drawings
Rebar Detailing & Bar Scheduling for Concrete Construction
Reinforced concrete projects can require coordinated bar layouts, sections, bar marks and schedules for multiple structural elements.
Reinforcement drawings should remain coordinated with the underlying concrete geometry, openings and project changes.
- Foundation reinforcement
- Column reinforcement
- Beam reinforcement
- Slab reinforcement
- Wall reinforcement
- Bar bending schedules
- Revision coordination
Modular Project Documentation From Design to Installation
Modular and prefabricated projects often require a coordinated set of building, fabrication and field-installation documents.
The workflow can include model development, building layouts, elevations, sections, roof plans, foundations, shop drawings, fabrication details and erection documents.
- Modular building design
- 3D visualization
- Elevation drawings
- Section drawings
- Roof layout drawings
- Foundation drawings
- Fabrication drawings
- Erection drawings
Technical Outputs Built Around Project Requirements
The exact drawing and model package depends on the agreed scope, source information and construction workflow.
3D Models
Technical models supporting geometry review, coordination and drawing development.
Shop Drawings
Component-level documents communicating information required for production or construction.
Fabrication Drawings
Detailed workshop documentation for suitable steel, metal, modular or equipment components.
Erection Drawings
Field-placement documentation showing component locations and assembly relationships.
Coordination Drawings
Model- or drawing-based documentation supporting multidisciplinary interface review.
Schedules & Technical Data
Suitable project schedules such as reinforcement or component information where included in scope.
From Project Inputs to Coordinated Deliverables
Looking for Actual Drawing & Modeling Examples?
This page explains the types of projects and technical workflows we support.
The dedicated Portfolio page contains selected visual examples covering structural detailing, rebar, column covers, modular construction, shop drawings and 3D modeling.
View the 7Solutions India Portfolio →- Structural detailing samples
- Steel shop drawing samples
- Rebar detailing samples
- Architectural metal detailing
- Modular building models
- 3D visualization samples
- Construction drawing examples
